Specifications
| Particulars | Description |
|---|---|
| Ultrasonic Generator Power | Multi frequency operating system with self-tuning & ultrasonic intensity adjustment. Frequency & ultrasonic running current will be displayed in the generator. |
| Heater | High Density Cartridge Heaters |
| Transducers | Imported Transducers, PZT type made from Piezo rings |
| Transducer Bonding | Bottom + 4 sides |
| Temperature Controller | Digital type (0-80°C) |
| Water Inlet & Overflow System |
Inlet: 1” Pipe Overflow: 1” Pipe, top corner side of the tank |
| Drain | 1” PP Ball Valve |
| Water Level Sensor | 1 X Vibrating Fork Lever Type |
Interested in Buying?
Features
Tank MOC :
SS304
Outer Body MOC :
SS304
Ultrasonic Frequency :
37kHz and 68 kHz (+/- 3kHz)
Ultrasonic Timer :
0 – 99 Minutes
Ideal Cycle Time :
0 - 10 Minutes
Heater Temperature :
Ambient to 70 degree
Temperature Controller :
Digital
Inlet :
1’’ BSP Valve
Drain :
1’’ BSP Valve
Supply Voltage :
230 V, 50Hz, Single Phase
Basket :
SS304 Mesh Type
Degas Mode :
Available
Semiwave Mode:
Available
Power Regulation :
Analog Type ( only in Marvel – S/R Series )
Add-Ons & Customisations
Rinsing & Drying
For comprehensive cleaning requirements, we offer additional process customizations to achieve the cleanliness or drying benchmark.
Automatic Water Inlet & Outlet
We also offer automatic water inlet and outlet features to fully automate the water inflow & outflow.
Tank Size Customization
Apart from the available standard tank sizes, we also offer customized tank sizes based on the user requirement.
Basket Customization
At your service, we craft the ideal basket, adjusting its depth, dimensions, and design, all tailored to your unique needs and desires.
Panel Box
| Particulars | Description |
|---|---|
| Power Supply | 415 V, 3 Phase, 50Hz |
| Operation | 24 Volts Push Buttons |
| Electronics Accessories |
Contactors: Siemens / Schneider / ABB Relay: Omron / Phoenix Contact Ultrasonic Generator Board: Waveultra Timer: Autonics / Multispan Temperature Controller: Autonics / Multispan Switches: Siemens / Schneider / ABB |
| Emergency Push Button | SCHMERSAL / Schneider |
| Power Supply | Omron / Autonics |
| Safety Relay | SCHMERSAL |
| RTD Sensor | PT100 |
